PANDUIT Mini-Com® Cat6a RJ45 Universal TG Module | UTP

Panduit’s Mini-Com® TX6A™ 10Gig UTP Jack Module delivers reliable, high-density 10-gigabit performance for next-generation network infrastructures. As part of the TX6A 10Gig UTP Copper Cabling System with MaTriX Technology, this jack module provides a cost-effective solution that ensures network bandwidth requirements are met.

The TX6A 10Gig UTP Jack Module is a Category 6A/Class EA, 8-position unshielded jack that terminates 4-pair, 22–26 AWG, 100-ohm unshielded twisted pair cable without the need for a punchdown tool. The blue, color-coded termination cap identifies Cat6A performance and includes a universal wiring label that supports both T568A and T568B wiring schemes. When installed as part of the TX6A 10Gig UTP Copper Cabling System, the jack achieves IEEE 10GBASE-T certified performance.

Certified to ISO/IEC 11801 Class EA, ANSI/TIA-568.2-D Category 6A, and IEEE 802.3an-2006 standards, Mini-Com TX6A 10Gig UTP Jack Modules support high-bandwidth applications such as 10GBASE-T and HDBaseT.

Innovative MaTriX split foil technology provides alien crosstalk suppression, making the TX6A 10Gig UTP solution well suited for high-density installations where performance margins are essential. Each jack module is 100% performance tested, ensuring consistent electrical performance and installation confidence. Individually serialized modules allow for quality control tracking and future traceability.

The modular Mini-Com design allows the jack module to snap easily into compatible faceplates, patch panels, and surface mount boxes, offering flexibility for any changes.
