LEVITON Atlas X1 Cat6A Quickport Jack | UTP
LEVITON Atlas X1 Cat6A Quickport Jack | UTP
Out of stock — available to order, dispatched in approx. 20 working days
SKU: LN-6AUJK-RE6MFN: 6AUJK-RE6
Regular price
£7.00 GBP
Regular price
Sale price
£7.00 GBP
Ex VAT
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Leviton’s ATLAS-X1™ Cat 6A QuickPort® Jack UTP is part of Leviton’s complete ATLAS-X1 Cat 6A UTP system. It meets or exceeds channel and component-level performance requirements defined by ANSI/TIA-568.2 Category 6A, ISO/IEC 11801-1 Class EA, and EN 50173-1 Class EA. It is compliant with ANSI/TIA-1096-A, c(UL)us Listed, independently verified for electrical transmission performance and power delivery, and fully supports IEEE 802.3 PoE Types 1, 2, 3, and 4, delivering up to 100 watts for high-power devices.
Featuring a die-cast zinc body and high-impact, fire-retardant plastic components rated UL 94V-0, the ATLAS-X1 jack is built for durability and safety. The solid metal body dissipates up to 53% more heat than traditional plastic designs, reducing thermal stress in PoE applications.
The jack features a short, compact design that supports installation in shallow boxes, enclosures, and tight bend-radius environments. Capable of terminating 26 to 22 AWG solid or stranded conductors, the jack is rated for 20 re-termination cycles and 3,000 plug insertions to ensure reliability.
It is available in 14 ANSI/TIA-606-C compatible colours, standard or shuttered styles, and select versions with interchangeable icons.
Featuring a die-cast zinc body and high-impact, fire-retardant plastic components rated UL 94V-0, the ATLAS-X1 jack is built for durability and safety. The solid metal body dissipates up to 53% more heat than traditional plastic designs, reducing thermal stress in PoE applications.
The jack features a short, compact design that supports installation in shallow boxes, enclosures, and tight bend-radius environments. Capable of terminating 26 to 22 AWG solid or stranded conductors, the jack is rated for 20 re-termination cycles and 3,000 plug insertions to ensure reliability.
It is available in 14 ANSI/TIA-606-C compatible colours, standard or shuttered styles, and select versions with interchangeable icons.
